GL 7500 SECUMAX NANOGL 7500 SECUMAX MICRO
GL 7500 SECUMAX NANO

GLIDELUX SECUMAX The most Premium Galvalume/Stainless Steel Prefinished Perforated Residential Screens, GL7500 with a very special High Strengthened compact profile of Height 75mm And Minimum Thickness Of 1.05mm. The profile is with Automated High Precision Perforation NANO/MICRO with 80-85% transparency with all-round nylon beading. This advanced profile is designed by Distinctive Extruded Aluminum Guides with Double side vertical weather seal and a Precisely Engineered Extruded Aluminum Bottom profiles, ensuring a Perfect Weather Seal for smooth greaseless and sound free operations.

The drive of the screen is normally featured with Specially Designed & Highly Spring Balanced 60mm Heavy Duty Pipe Shaft assembled by 6213 pre-greased sealed bearing; The Special Heavy Duty Cage design is capable to withstand break load of 3.25 tone with NICE Brand the most trusted Direct coupled Italian Automation System.

Key Features

Autolocking Compact Size Heavy Duty Any RAL Color powder-coating Air Circulation Manual Override

Drive Options

Tubular Drive

Side Drive

Centre Drive

Base material

Marine Grade High-Tensile Galvalume pre-finished color coated steel

Material thickness

1.05mm to 1.20mm

Screen Locking

Double side interlocking + double side nylon beading on both sides end to end

Profile Height

75mm

Profile Shape

Full flat (Compact profile- Specially designed for Homes)

Perforation method

CNC Nano Perforation (Double lines-Design Patented)

Transparency

Min 90%

Protective Coating

Zinc + Aluminum Coating

Protective Coating Combination

55% of aluminium 43.4% zinc & 1.6% silicon

Protective coating Thickness

150GSM

Extra Coating

Premium Exterior Powder coating

Weight

10.5Kg/m2 approx.

Strength

550mpa tensile strength

Maximum Span

4.5 mtr.

GL 7500 SECUMAX MICRO

GLIDELUX SECUMAX The most Premium Galvalume/Stainless Steel Prefinished Perforated Residential Screens, GL7500 with a very special High Strengthened compact profile of Height 75mm And Minimum Thickness Of 1.05mm. The profile is with Automated High Precision Perforation NANO/MICRO with 80-85% transparency with all-round nylon beading. This advanced profile is designed by Distinctive Extruded Aluminum Guides with Double side vertical weather seal and a Precisely Engineered Extruded Aluminum Bottom profiles, ensuring a Perfect Weather Seal for smooth greaseless and sound free operations.

The drive of the screen is normally featured with Specially Designed & Highly Spring Balanced 60mm Heavy Duty Pipe Shaft assembled by 6213 pre-greased sealed bearing; The Special Heavy Duty Cage design is capable to withstand break load of 3.25 tone with NICE Brand the most trusted Direct coupled Italian Automation System.

Key Features

Autolocking Compact Size Heavy Duty Any RAL Color powder-coating Air Circulation Manual Override

Drive Options

Tubular Drive

Side Drive

Centre Drive

Base material

Marine Grade High-Tensile Galvalume / Stainless Steel Grade 304 Prefinished color coated

Material thickness

1.05mm to 1.20mm

Screen Locking

Double side interlocking + double side nylon beading on both sides end to end

Profile Height

75mm

Profile Shape

Full flat (Compact profile- Specially designed for Homes)

Perforation method

CNC Micro

Transparency

80-85%

Protective Coating

Zinc+ Aluminium Coating for GL

Protective Coating Combination

55% of aluminium 43.4% zinc & 1.6% silicon For GL

Protective coating Thickness

150GSM for GL

Extra Coating

Premium Exterior Powder coating

Weight

13.5Kg/m2 approx.

Strength

550mpa tensile strength

Maximum Span

6 mtr.
